Operating Range
Capacity : Up to 300 M3/hr
Head : Up to 60 mtr
Discharge Size : 25 mm to 100 mm
Temperature : Up to 70°C
Pressure : Up to 6 Kg/cm2
Speed : Up to 3500 rpm
Material of Construction
PP, PPCP, UHMWPE
Applications
• Electro Plating, Pickling & Steel Rolling Mills.
• Water Treatment Plant (ETP/STP), Effluent Treatment Plant.
• Excellent for Transfer and Loading-unloading like HCL, Sulfuric Acid/Alkali and Caustic Liquid.
• Scrubbing of Corrosive Gases like NH3, CO2, SO3, SO2, Br2, Cl2.
• For Handling Liquids in Various Industries like Textile, Paper, Cellulose, Sugar, Steel, Food, Having Temperature Range, Materials.
• Ideal for Circulation of Chemical in Metal Finishing Industry.
• Natural Choice for Pickling Line & Scrubber in Steel Plants.
• Filter Press for Dyes & Chemicals, Descaling, Oil & Other Fuels.
Features
• Designed to suit extremely corrosive duties in the process & chemical industries.
• Suitable for continuous service.
• Self-venting type casing.
• Pump casing is provided with external metal ring for construction stability.
• Grease / oil lubricant bearings.
• Pumps are fitted with either mechanical seal or gland packing depending on the service conditions.
• Shaft & sleeve of different material depending on the compatibility of the liquid to be handled.
• Can be supplied bare-shaft or with IE3 motors for energy saving.
Capacity : Up to 300 M3/hr
Head : Up to 60 mtr
Discharge Size : 25 mm to 100 mm
Temperature : Up to 70°C
Pressure : Up to 6 Kg/cm2
Speed : Up to 3500 rpm
Material of Construction
PP, PPCP, UHMWPE
Applications
• Electro Plating, Pickling & Steel Rolling Mills.
• Water Treatment Plant (ETP/STP), Effluent Treatment Plant.
• Excellent for Transfer and Loading-unloading like HCL, Sulfuric Acid/Alkali and Caustic Liquid.
• Scrubbing of Corrosive Gases like NH3, CO2, SO3, SO2, Br2, Cl2.
• For Handling Liquids in Various Industries like Textile, Paper, Cellulose, Sugar, Steel, Food, Having Temperature Range, Materials.
• Ideal for Circulation of Chemical in Metal Finishing Industry.
• Natural Choice for Pickling Line & Scrubber in Steel Plants.
• Filter Press for Dyes & Chemicals, Descaling, Oil & Other Fuels.
Features
• Designed to suit extremely corrosive duties in the process & chemical industries.
• Suitable for continuous service.
• Self-venting type casing.
• Pump casing is provided with external metal ring for construction stability.
• Grease / oil lubricant bearings.
• Pumps are fitted with either mechanical seal or gland packing depending on the service conditions.
• Shaft & sleeve of different material depending on the compatibility of the liquid to be handled.
• Can be supplied bare-shaft or with IE3 motors for energy saving.
