Operating Range
Capacity : Up to 1200 M3/hr
Head : Up to 150 mtr
Discharge Size : 25 mm to 300 mm
Temperature : Up to 350°C
Pressure : Up to 15 Kg/cm2
Speed : Up to 3500 rpm
Material of Construction
C. I, C.S, SS-304 / 304L, SS316 / 316L, Bronze, Alloy-20, CD4MCU Hast alloy B & C, etc.
Duplex stainless steel, super duplex stainless steel
Applications
• Hot & cold water circulation, cooling water circulation.
• Drip irrigation, water supply and building services.
• Thermic fluid, Jet dyeing, volatile fluids.
• Condensate handing, firefighting system, ETP/STP.
• Engineering, marine, refrigeration and cooling tower.
• Chemicals, petrochemicals, refineries, sugar, pulp & paper, laminates industries.
• Power plants, desalination plants, steel plants, rubber, Organic and inorganic chemical, DM water, sea water.
• Food, salt, textile and general industries services. Corrosive and abrasive process chemicals like acids, alkalis, Solvents, slurries, hydrocarbons, crystallizing liquids, nitric, Ammonia, fertilizer, hos hate.
• Chemical effluents.
Features
• Back pull out design.
• Conforming to DIN 24256/ISO 2858 Dimensions
• High efficiency hydraulic design.
• Heavy duty shaft, sleeve and bearings.
• Low NPSH.
• Noise and maintenance free.
• Single & double mechanical seal.
• Closed impeller with multi vane providing axial balancing of impeller loads.
• Steady head and capacity.
• One roller bearing on pump end, two angular contact ball bearings.
• Grease or oil lubricated bearings
• Several flange drilling options according to valid standards.
• Suitable with V-belt drive or direct coupled with a motor.
• Foot and centerline mounting options.
• Can be supplied bare-shaft or with IE3 motors for energy saving.
Capacity : Up to 1200 M3/hr
Head : Up to 150 mtr
Discharge Size : 25 mm to 300 mm
Temperature : Up to 350°C
Pressure : Up to 15 Kg/cm2
Speed : Up to 3500 rpm
Material of Construction
C. I, C.S, SS-304 / 304L, SS316 / 316L, Bronze, Alloy-20, CD4MCU Hast alloy B & C, etc.
Duplex stainless steel, super duplex stainless steel
Applications
• Hot & cold water circulation, cooling water circulation.
• Drip irrigation, water supply and building services.
• Thermic fluid, Jet dyeing, volatile fluids.
• Condensate handing, firefighting system, ETP/STP.
• Engineering, marine, refrigeration and cooling tower.
• Chemicals, petrochemicals, refineries, sugar, pulp & paper, laminates industries.
• Power plants, desalination plants, steel plants, rubber, Organic and inorganic chemical, DM water, sea water.
• Food, salt, textile and general industries services. Corrosive and abrasive process chemicals like acids, alkalis, Solvents, slurries, hydrocarbons, crystallizing liquids, nitric, Ammonia, fertilizer, hos hate.
• Chemical effluents.
Features
• Back pull out design.
• Conforming to DIN 24256/ISO 2858 Dimensions
• High efficiency hydraulic design.
• Heavy duty shaft, sleeve and bearings.
• Low NPSH.
• Noise and maintenance free.
• Single & double mechanical seal.
• Closed impeller with multi vane providing axial balancing of impeller loads.
• Steady head and capacity.
• One roller bearing on pump end, two angular contact ball bearings.
• Grease or oil lubricated bearings
• Several flange drilling options according to valid standards.
• Suitable with V-belt drive or direct coupled with a motor.
• Foot and centerline mounting options.
• Can be supplied bare-shaft or with IE3 motors for energy saving.
